Fully discrete analog stages without any OPA and couple caps in the signal channels.
Non- feedback ACSS analog output stage .
Total of 8 groups dedicated power circuits are used to purify the
power supply.
Applies a custom order ALPS 27 volume pot for reducing channel
imbalance and improving on sound quality.
3 channels digital input :
coaxial / Optical / USB
DAC output :
RCA (User can setting with either variable and
fixed output level )
Headphone output :
6.3MM SE
USB Audio Class 2 High-speed Input from PC/MAC (NFB-5.2)
Supports full speed Asynchronous Transfer Mode (NFB-5.2)
Resolutions support 16 / 24-Bit with sampling rate support 44.1kHz,
48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz (NFB-5.2 USB model)
Supports up to 24Bit/192KHz (coaxial )
Supports 2X , 4X and 8X oversampling customers setting
Memorizes all settings and it could resume the last settings when
power on.
Sound Characteristics:
NFB-5 can bypass the OPA for best neutral sound or replace the OPA
for different sound flavors.
"Neutral but smoothness sounding ,it
doesn't sound skeletal or digital (or metallic). There's meat aplenty on
them bones . It's a sigma-delta DAC chip implementation without the
dryness, neutrality without the emotional disconnection" - John Darko
|
Summarize
